Characteristics

• 3 Pass Design Multi Start Coil
• Higher Heat transfer Area Of 9 to 10 Square Meter Per 1 lac Kcal/hour his Provided
• Multi fuel Option
• FBC Automatic Fuel feeding System
• Long thermic fluid life
• Corrosion free
• No scale problems
• No boiler regulation
• High temperature
• Abrasion resistant
• Easy to use

It consists of followings

• 3 pass double coil Assembly
• Air Preheater
• Multi Cyclone Dust Collector
• Trema Cyclone-Cyclomax. or
• Wet Scrubber
• Furnace with Fire Doors & Ash Doors
• Fire Bars or Air Nozzel Box. Screw Feeder
• Expansion Cum Deaerator Tank
• High temperature re-circulating pumps
• Advanced safety features
• Complete control panel

Specifications

Abnormal Condition	Safety Action
Low Thermic Fluid Flow	Differential pressure switch (DPS) across inlet and outlet headers cuts of the ID Fan slowing down combustion.
Thermic Fluid system pressure high due to system valves closure etc.	Pressure switch cuts of ID Fan and alarm. Safety relief valve (Optional) to be provided in the system piping so as to by pass the oil.
Thermic Fluid Temperature High	Digital Temperature cuts of ID fan at set point.
Coil Chocking	Differential pressure Switch (DPS) across system cuts of the ID Fan Slowing down combustion.
Thermic Fluid Motor Trip	Electrical Interlock cuts of fans.
Power Failure	Diesel Engine (Optional) keeps thermic fluid moving to avoid overheating and overflow of oil. Exhaust with Damper provided on furnace to drive away hot gases directly.
